LD Systems - Contrôleur DSP 19" 6 canaux
Le LD DPA-260 est un processeur d’enceintes 6 canaux, rackable 19 pouces (1 U), pour nos arrays VA-4, VA-8 et UNO.
Caractéristiques :
-
Type : DSP Controller for Line Array VA-4, VA-8 and UNO
-
Model Name : DPA-260
-
Description : 6-Channel 19" speaker processor, 32bit DSP, 24bit AD/DA (48 kHz) converter
-
Inputs : 2 Channels Analog/Digital, L + R, Noise Gate, the inputs and outputs are freely assignable, that means you can assign any input to any output and vice versa
-
Input EQ : 5 Band PEQ, Low Shelf and High Shelf Types available
-
Crossover Range : 20 Hz - 20 kHz
-
Outputs : 6 Channels, High/Low Pass Filter, Filtertype and dB available, 7 Band PEQ, Low Shelf and High Shelf Types available, Limiter with Threshold, Attack and Release Parameters
-
Delay : Time or Meter available, Max. Delay up to 848 ms
-
Phase Invert Function : USB Port, Full programmable Software included with 24 Memory Capacity for Presets
-
Display : 2 × 16 character LCD with backlight
-
Switch mode power supply : 90 V - 250 V
-
Dimensions : 19" / 1U
|
